AG 104 PLUS
Universal Mechanisms
- New back flow protection to prevent contamination;
- Compliant with UK standards;
- Side or bottom water supply connection;
- ½” plastic connection;
- Delayed refilling inlet valve: it starts after the outlet valve is in the
- closed position;
- Easy maintenance without the need to disconnect from the water connection;
- Dynamic pressure functioning range: 0.1 – 10 bar;
- Maximum static pressure: 16 bar;
- 10 year warranty.
Code . 883103
Characteristics
- New back flow protection to prevent contamination;
- Compliant with UK standards, WRAS;
- Side or bottom water supply with ½” plastic connection;
- Delayed refilling inlet valve: it starts after the outlet valve is in the closed position;
- Easy maintenance without the need to disconnect from the water connection;
- Counter pressure closing system (hydraulic);
- Dynamic pressure functioning range: 0.1 – 10 bar;
- Maximum static pressure: 16 bar;
